Product details
The LabJack T8 is the new flagship T-Series device adding powerful features including:
- 8x isolated analog inputs (AIN) with simultaneous sampling.
- ±1 kV AIN isolation channel-to-channel and channel-to-ground.
- Top performance for thermocouples, load cells, bridge circuits, and more.
- 8x 24-bit ΣΔ ADCs (up to 40k samples/s/ch).
- 10+ AIN voltage ranges: ±11V, to ±0.075V.
- 2 analog outputs (16-bit, 0-10V) with 20 mA drive.
- 20 digital I/O similar to the T7.
- Lua scripts are faster with 5x the code space than the T7.
- 3.3V fixed voltage outputs for excitation.
- Supported by LJM. LabJack’s free, 3rd generation, cross-platform driver/library/API for simplifying device communication.
- Industrial temperature range (-40 to +85C).
- USB & Ethernet.
- Built-in Power over Ethernet (PoE), or power through USB connection.
Isolated, Simultaneous, High Speed Analog & Digital Measurements
The LabJack T8 is our 2022 new flagship device, capable of collecting signals from virtually any kind of sensor. With instrumentation amplified inputs, software selectable gain settings, many digital I/O features, and a Modbus TCP front-end, the T8 is our most versatile multifunction DAQ platform. Common applications include sampling large industrial signals requiring electrical isolation and/or precision timing including EV battery testing, industrial control and monitoring, automated testing, and prototype development. Additionally, T8 devices are capable of stand-alone operation by running Lua scripts and include 5x more space for Lua scripts than other T-Series devices.
T8 Analog Input Features
- 8 Fully Isolated, differential Analog Inputs built in
- 1kV channel-to-channel and channel-to-ground isolation
- 24-bit high-speed ADC (up to 40,000 samples per second per channel) (Appendix A-1)
- Simultaneous, independent ADC per channel
- Software Configurable Resolution Settings
- Voltage Ranges: ±11V, ±9.7V, ±4.8V, ±2.4V,±1.2V, ±0.6V, ±0.3V, ±0.15V,±0.075V, ±0.036V, and ±0.018V (Appendix A-3-3)
- All analog input features are software programmable by configuring the Analog Input Registers
- High speed sampling configurable by using Stream Mode. Speeds up to 40kS/s/Ch
- Low Latency Sampling and Control (less than 1ms) is made easy with Command-Response Modbus messages
- Easy integration with sensors like thermocouples, load cells, bridges, and more Explore LabJack’s Sensor App-Notes
T8 Analog Outputs
- 2 analog outputs (16-bit, 0-10V)
- Waveform generation via Stream Out
- Source Impedance/Load Current compensated up to 20mA
- Vout Min -0.0 Vout Max 10.0
The DACs on the T8 use additional power systems to output voltage levels above and below the supply. This allows the T8 to output approximately -0.1 to 10 V as long as the supply voltage is within the valid operating range.
The DACs on the T8 have good load regulation. Very little voltage drop is expected up to 20mA, usually 1-2 mV.
T8 Digital I/O
- 20 Digital I/O-Use our CB15 Terminal Board for access to all DIO
- Supports SPI, I2C, and more… (Master Only)
- up to 9 PWM Outputs with individual phase control
- up to 9 Pulse Outputs with configurable number, frequency, and width
- up to 9 Frequency Inputs returning both frequency and period
- up to 9 Pulse Width Inputs measuring time spent high and low as well as duty cycle
- up to 3 pairs Line-to-Line Inputs measuring the time between edges on 2 different lines
- up to 8 High-Speed Counters
- up to 16 Software Counters with debounce capabilities
- up to 8 Pairs of Quadrature Inputs
Many of these DIO Extended Features share pins and cannot be used at the same time. See the DIO Extended Features section of the T8’s datasheet
